導體
截面積
(mm2)
|
導體結構
根/(mm)
|
絕 緣 厚 度
(mm)
|
芯 數
|
護 套 厚 度
（mm）
|
導 體 電 阻
≤Ω/km
|
|||||
|
50KV-DC
|
40KV-DC
|
30KV-DC
|
20KV-DC
|
10KV-DC
|
鍍錫銅絲
|
鍍銀銅絲
|
||||
|
0.12
|
7/0.15
|
≥1.10
|
≥1.0
|
≥0.8
|
≥0.65
|
≥0.55
|
1-7芯
|
≥1.0
|
160
|
146
|
|
0.20
|
7/0.20
|
90.4
|
83.5
|
|||||||
|
0.35
|
19/0.16
|
≥1.15
|
≥1.05
|
≥0.85
|
≥0.65
|
≥0.58
|
53.1
|
49.5
|
||
|
0.50
|
19/0.18
|
39.7
|
36.0
|
|||||||
|
0.56
|
7/0.32
|
38.1
|
35.3
|
|||||||
|
0.75
|
19/0.23
|
≥1.3
|
24.6
|
23.7
|
||||||
|
0.85
|
7/0.40
|
23.9
|
22.2
|
|||||||
|
1.0
|
19/0.26
|
20.4
|
19.0
|
|||||||
|
1.35
|
19/0.30
|
≥1.5
|
15.9
|
14.7
|
||||||
|
2.0
|
19/0.37
|
9.62
|
8.98
|
|||||||
