Mobile fire retardant rubber soft cables for mines
|
產品用途:產品供煤礦移動電器設備及采掘機械配套用。
Scope of application:The product necessary uses for the coal mine migration electric appliance equipment and the excavation machinery
執行標準 Standards implemented: MT 818-1999
|
 |
型號名稱 Model descriptions
|
型 號
Model
|
名 稱
Descriptions
|
|
MY
|
煤礦用移動橡套軟電纜
Mobile rubber soft cables for mines |
|
MYQ
|
煤礦用移動輕型橡套軟電纜
Mobile light type rubber soft cables for mines |
|
MYP
|
煤礦用移動屏蔽橡套軟電纜
Mobile shielded rubber soft cables for mines |
|
MC
|
采煤機橡套軟電纜
Rubber soft cables for coal cutter in mines |
|
MCP
|
采煤機屏蔽橡套軟電纜
Shielded rubber soft cables for coal cutter in mines |
|
MZ
|
煤礦用電鉆橡套電纜
Electric drill rubber cables for mines |
|
MZP
|
煤礦用電鉆屏蔽橡套電纜
Electric drill shielded rubber cables for mines |
使用特性
Service characteristics
|
型 號
Model
|
MYQ MZ MZP MY MYP MC MCP
|
額定電壓
U0/U Rated voltage |
0.3/0.5kv 0.38/0.66kv 0.66/1.14kv |
電纜長期允許工作溫度
Long-term service temperature of the cable conductor |
65℃ |
電纜的最小彎曲半徑
Minimun bending radius |
6D |
電纜規格 Specifications
|
型 號
Model
|
芯 數
Core number
|
額定電壓 KV
Rated voltage
|
標稱截面mm2
Nominal sectional
|
|
動力線芯
Core for power
|
地線芯
Core for ground
|
控制線芯
Pilot wire core
|
|
MY
|
1 |
0.38/0.66 |
50-150 |
- |
- |
| 3+1 |
3x4-3x70 |
1x4-1x25 |
- |
|
MZ MZP
|
3+1、3+1+1 |
0.3/0.5 |
3X2.5-3X4 |
1X2.5-1X4 |
1X2.5-1X4 |
|
MYQ
|
2、3、4、7、12 |
0.3/0.5 |
1.0-2.5 |
- |
- |
| 3+1 |
3X1.0-3X2.5 |
1X0.75-1X1.5 |
|
MC
|
3+1+3 |
0.38/0.66 |
3x16-3x50 |
1x4-1x10 |
3x2.5-3x4 |
|
MCP
|
3+1+3 |
0.38/0.66 |
3x16-3x50 |
1x4-1x10 |
3x2.5-3x4 |
| 0.66/1.14 |
3x35-3x95 |
1x6-1x25 |
|
MYP
|
3+1 |
0.38/0.66 |
3x4-3x70 |
1x4-1x25 |
- |
| 0.66/1.14 |
3x10-3x95 |
1x10-1x25 |
電纜主要技術性能
Major technical performances
1、 電纜導體直流電阻
DC resistance of the conductor
型 號
Model |
標稱截面
Nominal sectional
(mm2)
|
200C時導體直流電阻(≤Ω/Km)
DC resistance of the conductor at 20℃
|
型 號
Model
|
標稱截面
Nominal sectional
(mm2)
|
200C時導體直流電阻(≤Ω/Km)
DC resistance of the conductor at 20℃
|
|
不鍍錫
Untinned
|
鍍錫
Tinned
|
不鍍錫
Untinned
|
鍍錫
Tinned
|
| MYQ |
1.0
|
19.5
|
20.0
|
MY
MYP
|
10
|
1.91
|
1.95
|
|
1.5
|
13.3
|
13.7
|
16
|
1.21
|
1.24
|
|
2.5
|
7.98
|
8.21
|
25
|
0.780
|
0.795
|
MZ
MZP |
2.5
|
-
|
8.82
|
35
|
0.554
|
0.565
|
|
4
|
-
|
5.39
|
50
|
0.386
|
0.393
|
MC
MCP |
4
|
-
|
5.09
|
70
|
0.272
|
0.277
|
|
6
|
-
|
3.39
|
95
|
0.206
|
0.210
|
|
10
|
-
|
1.95
|
120
|
0.161
|
0.164
|
|
16
|
-
|
1.24
|
150
|
0.129
|
0.132
|
|
25
|
-
|
0.795
|
185
|
0.106
|
0.108
|
|
35
|
-
|
0.565
|
240
|
0.0801
|
0.0817
|
|
50
|
-
|
0.393
|
300
|
0.0641
|
0.0654
|
MY
MYP |
4
|
4.95
|
5.09
|
400
|
0.0485
|
0.0495
|
|
6
|
3.30
|
3.39
|
-
|
-
|
-
|
2、 電纜的絕緣電阻 Dielectric resistance
|
型 號
Model
|
動力線芯標稱截面mm2
Core for power nominal sectional
|
20℃時絕緣電阻
(≥MΩ Km)
Dielectric resistance at 20℃
|
型 號
Model
|
動力線芯標稱截面mm2
Core for power nominal sectional
|
20℃時絕緣電阻(≥MΩ Km)
Dielectric resistance at 20℃
|
|
MYQ
|
1.0
|
160
|
MY
MYP
|
10
|
160
|
|
1.5
|
160
|
16
|
120
|
|
2.5
|
160
|
25
|
120
|
|
MZ
MZP
|
2.5
|
160
|
35
|
100
|
|
4
|
160
|
50
|
100
|
|
MC
MCP
|
16
|
120
|
70
|
80
|
|
25
|
120
|
95
|
80
|
|
35
|
100
|
120
|
50
|
|
50
|
100
|
150
|
50
|
|
70
|
80
|
185
|
50
|
|
95
|
80
|
240
|
50
|
|
限制線芯Control core
|
100
|
300
|
50
|
|
MY
MYP
|
4
|
200
|
400
|
50
|
|
6
|
180
|
-
|
-
|
3、電纜其它主要技術性能 Other major technical performances
(型 號 Model:MY MYP MYQ MC MCP MZ MZP)
|
序 號
Serial number
|
項 目
Items
|
技術性能
Technical performances
|
|
1
|
線芯直流電阻(≤Ω/Km)
Core DC resistance |
見上表
See above table |
|
2
|
絕緣電阻(≥MΩ Km)
Insulating resistance |
見上表
See above table |
|
3
|
5min工頻電壓試驗
5min power frequency voltage experiment |
0.66/1.14 |
3.7KV工頻電壓絕緣不擊穿
3.7KV power frequency voltage insulation does not penetrate |
| 0.38/0.66 |
3KV工頻電壓絕緣不擊穿
3KV power frequency voltage insulation does not penetrate |
| 0.3/0.5 |
2KV工頻電壓絕緣不擊穿
2KV power frequency voltage insulation does not penetrate |
| 控制線芯Control core |
1.5KV工頻電壓絕緣不擊穿
1.5KV power frequency voltage insulation does not penetrate |
|
4
|
熱延伸試驗
The heat extends the experiment |
≤175% |
|
5
|
單根垂直燃燒試驗
Single wire burning test |
MT386 |
|
6
|
成束燃燒試驗
Group burning test |
最大線芯截面積在50mm2及以上時 符合A類成束燃燒試驗要求
Max. core sectional area more than 50mm2 conforms A kind group burning test |
|
7
|
最大線芯截面積在50mm2及以下時 符合B類成束燃燒試驗要求
Max. core sectional area more than 50mm2 conforms B kind group burning test |
|
