應用范圍：
· 這種特殊電纜作為控制和監測信號的傳輸及電源連接，適用安裝在扭力和彎曲應力同時存在的各種場合
適合用于：
· 焊接機器人及機械手的連接和裝配，連接回旋式或升降工作臺，或因設計時無法設定電纜的移動(如拖鏈系統中)等場合的安裝
|
產品特性
· 優質的絕緣和平滑的特氟綸繞包屏蔽層，使該電纜在扭力和彎曲應力同時存在的情況下適用壽命延長
· 特殊聚氨酯混合料外護套，具有增強的耐油特性，抗磨損切割，抗微生物和水解，阻燃
· 其外護套的特性還能防止其它相鄰電纜與之粘連
|
電纜結構
· 多股細絞或精絞成束超細裸銅
· TPE 芯線絕緣
· 芯線色標見”技術參數”
· 芯線 (或線對)絞合成纜
· 特氟綸繞包
· 屏蔽型(DP)：鍍錫銅絲繞包層
· 特制聚氨酯外護套
· 黑色 (RAL 7016)
|
|
技術參數
|
|
|
|
|
|
G=有綠/黃雙色接地標識; X=無綠/黃雙色接地標識。
|
|
物料
編號
|
導體截面積
|
電纜近似
|
電纜耗銅
|
電纜重量
|
|
mm2
|
外徑mm
|
量kg/Km
|
kg/km
|
|
|
JUFLEX- ROBOT 900 P
|
||||
|
JT3201701
|
7 X 0,25
|
6,2
|
16,8
|
48,0
|
|
JT3201702
|
25 X 0,25
|
10,2
|
60,0
|
141,0
|
|
JT3201703
|
2 X 0,34
|
5,0
|
7,0
|
27,0
|
|
JT3201704
|
18 G 0,5
|
11,2
|
84,6
|
120,0
|
|
JT3201705
|
25 G 0,5
|
13,3
|
120,0
|
254,0
|
|
JT3201706
|
4 G 0,75
|
6,6
|
28,8
|
63,0
|
|
JT3201707
|
14 G 0,75
|
11,4
|
100,8
|
199,0
|
|
JT3201708
|
2 X 1,0
|
6,2
|
19,2
|
47,0
|
|
JT3201709
|
3 G 1,0
|
6,5
|
29,0
|
61,0
|
|
JT3201710
|
4 G 1,0
|
7,2
|
38,4
|
76,0
|
|
JT3201711
|
7 G 1,0
|
9,3
|
67,2
|
131,0
|
|
JT3201712
|
12 G 1,0
|
11,5
|
115,2
|
216,0
|
|
JT3201713
|
16 G 1,0 + (2 X 1 DP)
|
16,5
|
195,0
|
376,0
|
|
JT3201714
|
18 G 1,0
|
13,2
|
172,8
|
304,0
|
|
JT3201715
|
23 G 1,0 + (2 X 1 DP)
|
17,3
|
262,0
|
470,0
|
|
JT3201716
|
25 G 1,0
|
16,4
|
240,0
|
433,0
|
|
JT3201717
|
34 G 1,0
|
18,9
|
326,4
|
565,0
|
|
JT3201718
|
41 G 1,0
|
21,4
|
393,6
|
696,0
|
|
JT3201719
|
18 G 1,5
|
15,8
|
259,2
|
446,0
|
|
JT3201720
|
25 G 1,5
|
19,7
|
360,0
|
638,0
|
|
JT3201721
|
3 G 2,5
|
9,3
|
72,0
|
136,0
|
|
JT3201722
|
4 G 2,5
|
10,1
|
96,0
|
171,0
|
|
JT3201723
|
3 G 4
|
12,3
|
116,0
|
226,0
|
|
JT3201724
|
3 G 10
|
18,3
|
288,0
|
517,0
|
|
JT3201725
|
3 G 16
|
21,4
|
460,8
|
721,0
|
|
JT3201726
|
3 G 25
|
26,2
|
720,0
|
1178,0
|
|
JT3201727
|
3 G 35
|
28,8
|
1008,0
|
1559,0
|
|
JUFLEX- ROBOT 900 DP
|
||||
|
JT3201728
|
12 X 0,14 DP
|
6,7
|
42,5
|
69,0
|
|
JT3201729
|
3 X 2 X 0,14 DP
|
5,9
|
17,0
|
44,0
|
|
JT3201730
|
25 X 0,25 DP
|
11,1
|
103,5
|
183,0
|
|
JT3201731
|
4 X 0,34 DP
|
5,7
|
21,3
|
46,0
|
|
JT3201732
|
5 X 2 X 0,34 DP
|
9,1
|
64,4
|
114,0
|
|
JT3201733
|
12 G 1,5 DP
|
14,0
|
259,0
|
395,0
|
|
JT3201734
|
18 G 1,5 DP
|
16,9
|
392,0
|
590,0
|
