RVV、RVVB型 銅芯聚氯乙烯絕緣聚氯乙烯護套圓型、平安安裝用軟電線
一、適用范圍
產品用于交流額定電壓300/300V和300/500V及以下的電器設備、照明、自動化裝置等在干燥及潮濕場所可移動的連接。
電線的線芯長期允許工作溫度不超過+70℃，電線的安裝溫度應不低于-15℃
二、產品標準：JBB734-98
三、技術參數
|
芯數×標準截面mm2
|
規格
|
絕緣厚度規定值mm
|
護套厚度規定值mm
|
20℃時導體電阻Ω/km不大于
|
|
銅芯
|
鍍芯銅芯
|
|
2×0.5
|
16/0.20
|
0.5
|
0.6
|
39.0
|
40.1
|
|
2X0.75
|
24/0.20
|
0.6
|
0.8
|
26.0
|
26.7
|
|
2X1
|
32/0.20
|
0.6
|
0.8
|
19.5
|
20.0
|
|
2X1.5
|
30/0.25
|
0.7
|
0.8
|
13.3
|
13.7
|
|
2X2.5
|
49/0.25
|
0.8
|
1.0
|
7.98
|
8.21
|
|
3×0.5
|
16/0.20
|
0.6
|
0.6
|
39.0
|
40.1
|
|
3X0.75
|
24/0.20
|
0.6
|
0.8
|
26.0
|
26.7
|
|
3X1
|
32/0.20
|
0.6
|
0.8
|
19.5
|
20.0
|
|
3X1.5
|
30/0.25
|
0.7
|
0.9
|
13.3
|
13.7
|
|
3X2.5
|
49/0.25
|
0.8
|
1.1
|
7.98
|
8.21
|
|
4X0.75
|
24/0.20
|
0.6
|
0.8
|
26.0
|
26.7
|
|
4X1
|
32/0.20
|
0.6
|
0.9
|
19.5
|
20.0
|
|
4X1.5
|
30/0.25
|
0.7
|
1.0
|
13.3
|
13.7
|
|
4X2.5
|
49/0.25
|
0.8
|
1.1
|
7.98
|
8.21
|
|
5X0.75
|
24/0.20
|
0.6
|
0.9
|
26.0
|
26.7
|
|
5X1
|
32/0.20
|
0.6
|
0.9
|
19.5
|
20.0
|
|
5X1.5
|
30/0.25
|
0.7
|
1.1
|
13.3
|
13.7
|
|
5X2.5
|
49/0.25
|
0.8
|
1.2
|
7.98
|
8.21
|
