產品用途:產品適用于煤礦井下無線電通訊設備和采用類似技術的電子裝置的有關無線電子設備中傳輸射頻信號。

Scope of application:The product is fit for the transmission of radio frequency signals in radio equipment or in electronic equipment adopting similar technologies.

執行標準 Standards implemented: Q/3210HL32-2005

型 號
Model

內導體(根數/直徑mm)
Inner conductor
(core No./dia)

標稱絕緣外徑mm
Nominal insulation outerdiameter

標稱電纜外徑mm
Nominal cable outer diameter

MSYV-50-2-1

7/0.16

1.5

2.8

MSYV-50-2-41

1/0.68

2.2

4.0

MSYV-50-3-1

7/0.32

2.95

5.0

MSYV-50-3-41

1/0.9

2.95

5.8

MSYV-50-5-1

1/1.4

4.8

7.2

MSYV-50-5-3

1/1.4

4.8

7.2

MSYV-50-7-1

7/0.76

7.3

10.3

MSYV-50-7-2

7/0.76

7.3

10.5

MSYV-50-9-41

7/0.95

9.0

12.2

MSYV-50-12-1

7/1.15

11.5

15.0

MSYV-75-2

7/0.08

1.5

2.9

MSYV-75-3-41

7/0.17

3.0

5.0

MSYV-75-5-41

1/0.75

4.8

7.2

MSYV-75-5-42

1/0.75

4.8

7.9

MSYV-75-7-1

7/0.40

7.3

10.3

MSYV-75-7-41

7/0.40

7.3

11.0

MSYV-75-9-41

1/1.37

9.0

12.2

MSYV-75-12-2

7/0.64

11.5

15.0

MSYV-75-15-41

7/0.82

15.0

19.0

MSYV-100-7

1/0.6

7.3

10.2
