| 規格參數(執行標準：JASO D611：2009) | |||||||||
| 型號 Style | 導體 Conductor | 絕緣 Insulation | 耐電壓Dielectric Strength AC | 長度 Length | |||||
| 標稱面積Nom. Area | 線數/線徑Num./Dia. | 直徑 Dia. | 厚度 Thick. | 完成外徑Nom.Dia. | 最大外徑Max.Dia. | 最小電阻Min.Resistance at 20℃ | |||
| m㎡ | NO./mm | mm | mm | mm | mm | mΩ/m | V/30min | M | |
| AV-80℃ | 0.3 | 11/0.18 | 0.28 | 0.7 | 2 | 2.2 | 56.3 | 3000 | 500 |
| 0.5 | 20/0.18 | 0.5 | 0.7 | 2.2 | 2.3 | 32.7 | 3000 | 500 | |
| 0.75 | 30/0.18 | 0.76 | 0.7 | 2.4 | 2.6 | 24.4 | 5000 | 500 | |
| 0.85 | 34/0.18 | 0.86 | 0.72 | 2.5 | 2.6 | 22.5 | 5000 | 500 | |
| 1 | 40/0.18 | 1 | 0.68 | 2.5 | 2.7 | 16.8 | 5000 | 500 | |
| AVS-80℃ | 0.75 | 30/0.18 | 0.76 | 0.5 | 2 | 2.1 | 24.4 | 5000 | 500 |
| AVSS-105℃ | 0.27 | 11/0.18 | 0.28 | 0.5 | 1.6 | 1.8 | 56.3 | 3000 | 1000 |
| 0.3 | 12/0.18 | 0.3 | 0.44 | 1.5 | 1.6 | 55.2 | 3000 | 1000 | |
| 0.35 | 13/0.18 | 0.33 | 0.43 | 1.5 | 1.6 | 54.8 | 3000 | 1000 | |
| 0.5 | 20/0.18 | 0.5 | 0.4 | 1.6 | 1.8 | 32.7 | 3000 | 500 | |
| 0.75 | 30/0.18 | 0.76 | 0.41 | 1.8 | 1.9 | 24.4 | 5000 | 500 | |
| 1 | 40/0.18 | 1 | 0.43 | 2 | 2.1 | 16.8 | 5000 | 500 | |
| AVE | 0.3 | 12/0.18 | 0.3 | 0.49 | 1.6 | 1.7 | 55.2 | 3000 | 500 |
| 0.5 | 20/0.18 | 0.5 | 0.6 | 2 | 2.1 | 32.7 | 3000 | 500 | |
| 0.75 | 30/0.18 | 0.76 | 0.66 | 2.3 | 2.4 | 24.4 | 5000 | 500 | |
